The Allen-Bradley 2711P-B10C4D6 is a high-performance operator terminal from the PanelView Plus 1000 series, engineered to provide reliable machine-to-operator interaction in demanding industrial environments. This unit features a 10.4-inch color display and a dual-input interface, combining both a tactile keypad and a responsive touchscreen for versatile control and monitoring of automation processes.
Features
- 10.4-inch color display for clear visualization of process data and alarms.
- Integrated keypad and touchscreen input options for flexible operator interaction.
- Built-in Ethernet and RS-232 communication ports for seamless network integration.
- Supports EtherNet/IP for real-time messaging and application data exchange.
- Compatible with modular communication expansion options for legacy system scalability.
Applications
This HMI terminal is designed for use in industrial automation systems requiring robust human-machine interfacing. It is commonly deployed in manufacturing lines, process control systems, and machinery management where reliable visualization and input control are critical for operational efficiency.
Technical Specifications
| Model |
2711P-B10C4D6 |
| Display Size |
10.4 in |
| Input Method |
Keypad and Touchscreen |
| Input Voltage |
18-32 VDC |
| Memory |
128 MB |
| Operating Temperature |
0 to 55 degC |
| Communication |
Ethernet (RJ45), RS-232 |
| Series Compatibility |
Ser A, B, C, D, F |
Installation Guidelines
- Ensure the terminal is mounted in a panel with adequate ventilation to maintain operating temperatures within the 0 to 55 degC range.
- Verify that the power supply provides a stable 18-32 VDC input before connection.
- Use shielded communication cables for Ethernet and RS-232 connections to minimize EMI interference in high-noise industrial environments.
- Always power down the unit before performing maintenance, replacing the backlight (2711P-RL10C), or installing communication modules.
- Adhere to standard ESD handling procedures when accessing internal components or memory modules.
FAQ
Is this unit still supported by the manufacturer?
The 2711P-B10C4D6 is classified as a legacy or discontinued product by Allen-Bradley. It remains a critical component for maintaining existing infrastructure and preventing unplanned downtime in legacy systems.
What communication modules are compatible with this terminal?
The unit supports expansion via modules such as the 2711P-RN20, which facilitates integration into various industrial communication architectures.
