Description
The 2711P-B10C15A7 is an operator terminal designed for machine interfacing in industrial automation environments, including manufacturing lines, water treatment facilities, and energy management systems. This HMI provides real-time visualization and control, facilitating precise operator inputs and system monitoring.
Features
- Dual input interface featuring both a keypad and a touchscreen for versatile data entry.
- Integrated ControlNet communication protocol supporting scheduled and unscheduled access to controller data.
- Supports symbolic CIP addressing for seamless integration with ControlLogix systems.
- Built-in Network Access port for local network connectivity.
- Accommodates redundant cabling configurations for high-availability network requirements.
Applications
This operator terminal is suitable for process control, machine status monitoring, and data logging in demanding industrial setups where reliable human-machine interaction is required.
Technical Specifications
| Model |
2711P-B10C15A7 |
| Brand |
Allen-Bradley |
| Display Size |
10.4 in |
| Display Type |
Color |
| Memory |
256 MB |
| Input Power |
85-264 VAC |
| Operating Temperature |
0 to 55 degC |
| Backlight Replacement |
2711P-RL10C |
| Series Compatibility |
Ser A, B, C, D, and F |
Installation Guidelines
- Ensure the device is installed in a clean, dry environment within the specified operating temperature range of 0 to 55 degC.
- Verify that the input power supply is within the 85-264 VAC range before connection.
- Use proper grounding techniques to prevent electrical noise interference and ensure stable operation.
- When installing in an enclosure, ensure adequate ventilation to maintain operating temperatures and prevent overheating.
- Always power down the unit before performing any wiring, maintenance, or component replacement.
- Handle with care to avoid damage to the touchscreen and keypad interface.
FAQ
What communication protocol does this unit use?
This model utilizes the ControlNet communication protocol for data exchange with controllers.
Can this unit be used with ControlLogix systems?
Yes, it supports symbolic CIP addressing, which allows for direct integration with ControlLogix controllers.
What is the replacement part for the backlight?
The compatible backlight replacement part number is 2711P-RL10C.
