The Allen-Bradley 2711E-UT12ET10 is a specialized hardware migration and adapter bezel kit designed to streamline the mechanical transition from legacy 12-inch PanelView 1200e touchscreen terminals to modern 10.4-inch PanelView 1000e units. This kit eliminates the requirement for structural modifications or additional sheet-metal fabrication on existing control enclosures, providing a secure and professional mounting solution for industrial HMI upgrades.
Features
- Engineered for precise dimensional transition between legacy 12-inch cutouts and 10.4-inch HMI form factors.
- Constructed from heavy-gauge carbon steel with a durable, industrial-grade powder coating.
- Includes high-density compression gaskets to maintain NEMA Type 4X and Type 12 enclosure integrity.
- Features pre-positioned mounting studs and integrated locking hardware for simplified installation.
- Designed to withstand high-vibration environments, protecting internal HMI components from mechanical fatigue.
Applications
This migration kit is primarily deployed in continuous-process industries where legacy HMI hardware requires replacement without disrupting the existing cabinet infrastructure. Typical applications include automotive assembly lines, water and wastewater treatment facilities, and chemical processing plants where maintaining environmental sealing is critical for equipment longevity.
Technical Specifications
| Model |
2711E-UT12ET10 |
| Primary Function |
Structural Bezel Adapter / Migration Kit |
| Compatibility |
PanelView 1200e to 10.4-inch PanelView 1000e |
| Material |
Heavy-gauge carbon steel |
| Enclosure Rating |
Maintains NEMA Type 4X / 12 |
| Operating Temperature |
0 to 50 deg C (32 to 122 deg F) |
| Storage Temperature |
-25 to 70 deg C |
Installation Guidelines
- Ensure the existing enclosure cutout is clean and free of debris before mounting the adapter plate.
- Verify that the compression gasket is seated correctly against the enclosure surface to ensure a proper seal.
- Tighten mounting hardware evenly around the perimeter to prevent warping and ensure uniform pressure distribution.
- Always disconnect power to the HMI terminal before performing any mechanical installation or maintenance.
- Ensure the installation environment remains within the specified temperature range to prevent thermal stress on the HMI display.
FAQ
Does this kit require cutting the existing panel? No, the 2711E-UT12ET10 is designed to fit the existing legacy cutout, removing the need for additional sheet-metal work.
Does this kit maintain the NEMA rating of the cabinet? Yes, when installed correctly with the provided compression gaskets, the kit is designed to maintain NEMA Type 4X and Type 12 environmental sealing.
