Allen-Bradley 1769-OF4VI CompactLogix Analog Voltage Output Module

Configured for isolated analog voltage signal execution in CompactLogix control systems, the Allen-Bradley 1769-OF4VI (1769-OF4VI Analog Output Module) provides direct physical/electrical output processing through four individually isolated channels.

Hardware Specifications

Parameter	Specification
Model	1769-OF4VI
Brand	Allen-Bradley
Origin	United States
Product Line	CompactLogix
Product Type	Analog Voltage Output Module
Module Type	Analog Current Output Module
Output Channels	4 individually isolated outputs
Output Signal Type	Voltage output
Series	Series A and B
Terminal Block	Replaceable terminal block
Replacement Door Part Number	1769-RD
Communication Interface	4 point connection
Wire Type	Copper-90 C
Solid Wire Size	22-14 AWG
Stranded Wire Size	22-16 AWG
Weight	0.44 lb (0.20 kg)
UNSPSC	32151705

EtherNet/IP and CompactLogix I/O Integration Characteristics

The 1769-OF4VI operates as a CompactLogix analog output component that connects through the controller backplane architecture. The module processes voltage output commands from the controller program and converts digital values into isolated analog signals.

Furthermore, the module supports I/O density scaling within CompactLogix platforms by providing four independent output channels in a compact form factor. The individually isolated channels reduce signal interaction between field devices and control logic circuits.

The module supports replaceable field wiring components, including the terminal block and module door. Therefore, maintenance personnel can replace these components without replacing the complete module assembly.

Frequently Asked Questions

Q: Does the 1769-OF4VI provide isolated output channels?
A: Yes. The module provides four individually isolated analog output channels for separate field signal connections.

Q: Can the terminal block be replaced if field wiring components are damaged?
A: Yes. The terminal block is replaceable, and the module door can also be replaced using the specified 1769-RD part.

Q: Does the module support grounding connections?
A: Yes. The 1769-OF4VI supports an earth ground connection for field installation safety requirements.

Field Installation Guidelines

Install the 1769-OF4VI in an appropriate CompactLogix chassis position according to the controller system configuration requirements.

Use copper conductors within the supported wire size range and maintain proper separation between analog signal wiring and high-voltage power conductors to reduce electrical interference.

Connect the earth ground terminal according to the installation design requirements. Verify field wiring polarity before applying system power to prevent incorrect analog output operation.

Inspect the removable terminal block connection points during commissioning and maintenance activities. Ensure that all field connections remain mechanically secured before returning the module to service.
