Keterangan
ABB DSQC608 Customer I/O Power Supply
The ABB 3HAC12934-1, also cataloged as the DSQC608 Customer I/O Power Supply, provides 24 VDC power distribution for external I/O devices within ABB IRC5 robot controller platforms.
Hardware Specifications
Parameter
Specification
Model
DSQC608
Brand
ABB
Origin
Sweden
Product Type
Customer I/O Power Supply Module
Spare Model
3HAC12934-1
System Compatibility
ABB IRC5 Robot Controller Series
Input Voltage
230 VAC, single phase
Input Frequency
50-60 Hz
Input Current
Max 3 A
Output Voltage
24 VDC
Output Current
8 A
Power Consumption
Approx. 200 W maximum output capability
Weight
1.38 kg
Dimensions
7.1 x 13.5 x 18.5 cm estimated shipping size
Operating Temp
-20 deg C to +60 deg C
ABB Industrial Control Bus and I/O Power Characteristics
The ABB DSQC608 operates as a dedicated power interface module for IRC5 controller I/O assemblies. It converts the incoming AC supply into regulated 24 VDC output power for connected customer I/O circuits and peripheral devices.
Additionally, the module supports ABB robot controller architectures where stable DC distribution is required for field signal components. The power supply design aligns with ABB industrial control hardware practices, including backplane power coordination, I/O density scaling, and controller cabinet integration.
The DSQC608 installation requires correct voltage selection, protective grounding, and appropriate cable routing to maintain electrical separation between power circuits and low-level I/O signal wiring.
Frequently Asked Questions
Q: What function does the ABB DSQC608 perform in an IRC5 controller system? A: The DSQC608 provides 24 VDC power output for customer I/O circuits and external devices connected to ABB IRC5 robot controller configurations.
Q: Does the DSQC608 support direct AC input connection? A: Yes. The module accepts 230 VAC single-phase input power and provides DC output for controller-related I/O applications.
Q: What installation considerations apply to the DSQC608? A: Installation requires correct cabinet mounting, protective earth connection, and separated routing between power cables and signal cables.
Field Installation Guidelines
Verify the controller cabinet power configuration before installing the DSQC608 module.
Connect protective earth according to ABB cabinet grounding practices.
Maintain separation between AC input wiring, 24 VDC output wiring, and sensitive I/O signal cables.
Check terminal connections for correct polarity before applying power.
Confirm that connected I/O loads remain within the module output current capability.
Inspect ventilation paths and mechanical mounting conditions during commissioning.
