ABB SD822 3BSC610038R1 Power Supply Module

The ABB SD822 3BSC610038R1, also cataloged as the SD822 Power Supply Module, operates as a dedicated hardware component for AC to 24 VDC power conversion within ABB industrial control system platforms. It provides a 230 VAC input interface and a 5 A rated 24 VDC output supply for connected control equipment.

Hardware Specifications

Parameter	Specification
Model	SD822 3BSC610038R1
Brand	ABB
Product Type	Power Supply Module
Origin	Sweden
Weight	0.6 kg
Dimensions	6.3 x 10.5 x 13.1 cm
Input Voltage	230 VAC
Output Voltage	24 VDC
Output Current	5 A
Power Supply	100 - 120 VAC
Power Consumption	150 VA typical
Operating Temp	0 - +50 deg C
Storage Temp	-40 - +70 deg C
Humidity	5 - 95 % RH non-condensing
Tariff Code	8537101190

Industrial Control Power Integration

The ABB SD822 power supply module supports industrial control power distribution through regulated 24 VDC output conversion. Furthermore, the module design aligns with ABB PLC and DCS hardware environments where stable DC power is required for I/O assemblies, controllers, and auxiliary control circuits.

ABB system power architectures typically use modular power distribution methods with controlled load allocation. Therefore, correct installation requires verification of input voltage range, output polarity, grounding arrangement, and connected load requirements before energizing the module.

The module operates as a power conversion component rather than a communication device. It does not provide field signal processing, protocol conversion, or I/O channel management functions. Its primary function is supplying DC operating power to compatible automation hardware.

Frequently Asked Questions

Q: What is the primary function of the ABB SD822 3BSC610038R1 module?
A: The SD822 3BSC610038R1 converts AC input power into a regulated 24 VDC output supply for ABB industrial automation equipment.

Q: Does the SD822 module provide communication or field signal interfaces?
A: No. The SD822 is a power supply module and does not include communication ports, analog input channels, or digital I/O functions.

Q: What environmental conditions are specified for SD822 operation?
A: The module supports an operating temperature range of 0 to +50 deg C and storage conditions from -40 to +70 deg C with 5 - 95 % RH non-condensing humidity.

Field Installation Guidelines

• Install the SD822 module according to the applicable ABB system cabinet layout and mounting requirements.
• Verify AC input wiring before connection to prevent incorrect voltage application.
• Maintain correct polarity when connecting the 24 VDC output terminals to downstream equipment.
• Connect protective grounding according to industrial electrical installation standards.
• Separate power wiring from sensitive signal cables to reduce electrical interference.
• Check terminal tightening conditions before system startup.
• Confirm the connected load remains within the specified power supply capacity.
