ABB 3BDM000210R1 TK 807F Supply Cable
The ABB 3BDM000210R1, also cataloged as the TK 807F Supply Cable, operates as a dedicated power connection component for AC supply distribution between SA 801F / SA 811F safety automation modules and their electrical supply network.
Hardware Specifications
Parameter
Specification
Model
3BDM000210R1
Brand
ABB
ABB Type Designation
TK 807F
Product Type
Prefabricated Cable
Cable Function
Supply Cable with Ferrules
Cable Length
2 m
Rated Voltage
115/230 VAC
Compatible Systems
SA 801F / SA 811F
Connector Configuration
Ferrule Termination
Origin
Sweden
Industrial Control Cable Integration and Electrical Connection
The ABB TK 807F supply cable provides a prefabricated connection path for AC power distribution within ABB safety automation configurations. The cable uses ferrule terminations to support direct cabinet wiring and terminal block installation.
Additionally, the 2 m cable length allows standardized routing between the supply source and SA 801F / SA 811F modules. The insulated conductor structure supports voltage levels up to 230 VAC according to the product specification.
For ABB industrial control systems, cable assemblies such as the TK 807F support I/O density scaling by reducing field wiring preparation time and maintaining consistent termination methods. The cable design also supports organized cabinet layouts with defined power routing paths.
Frequently Asked Questions
Q: What equipment is the ABB 3BDM000210R1 TK 807F designed to connect? A: The TK 807F is specified as a supply cable for SA 801F and SA 811F modules, providing 115/230 VAC power connection through ferrule terminations.
Q: Does the TK 807F include active electronic components? A: No. The TK 807F is a passive prefabricated cable assembly and does not contain processing, communication, or control electronics.
Q: What termination method does the cable use? A: The cable uses ferrule terminations designed for industrial terminal connection and cabinet wiring applications.
Field Installation Guidelines
Install the TK 807F according to the wiring requirements of the connected ABB safety automation hardware.
Verify the AC supply voltage level before connection and ensure correct terminal assignment during cabinet installation.
Route the cable separately from high-current switching conductors where possible to reduce electrical interference. Maintain proper cable bend radius and avoid mechanical stress on the ferrule ends.
Confirm that all ferrule connections are fully inserted and mechanically secured before energizing the system. Use standard industrial grounding and shielding practices when the installation environment requires additional noise protection.
