Bently Nevada 330104-00-05-05-01-00 3300 XL 8 mm Proximity Probe

The Bently Nevada 330104-00-05-05-01-00, also cataloged as the 330104 3300 XL 8 mm Proximity Probe, operates as a dedicated eddy-current sensing component for shaft displacement measurement within Bently Nevada TSI monitoring systems.

Hardware Specifications

Parameter	Specification
Model	330104-00-05-05-01-00
Brand	Bently Nevada
Product Type	3300 XL 8 mm Proximity Probe
Origin	USA
Weight	0.15 kg
Dimensions	Estimated shipping size: 1.8 x 1.6 x 121 cm
Power Consumption	Supplied by compatible proximity transducer system, not specified in provided data
Probe Type	Eddy-current displacement probe
Thread Type	M10 x 1 thread
Armor Option	Armored probe design
Unthreaded Length	0 mm
Overall Case Length	50 mm
Total Length	0.5 meter (1.6 feet)
Connector Type	Miniature coaxial ClickLoc connector with connector protector
Cable Type	Standard cable
Tariff Code	8537101190

Eddy-Current Measurement and Rotor Dynamics

The Bently Nevada 3300 XL 8 mm Proximity Probe uses eddy-current measurement technology to convert shaft surface movement into electrical displacement signals. Therefore, the probe provides dynamic and static shaft position information for machinery monitoring applications.

The probe design supports Bently Nevada proximity measurement systems by maintaining consistent probe scaling characteristics. Additionally, the system configuration allows engineers to validate gap voltage conditions, including the commonly applied -10 VDC target range for correct probe positioning.

The 330104-00-05-05-01-00 model includes a 0.5 meter standard cable assembly and miniature coaxial ClickLoc connector. Furthermore, the connector protector improves mechanical protection at the probe connection point during field installation.

Frequently Asked Questions

Q: What measurement technology does the 330104-00-05-05-01-00 probe use?
A: The probe uses eddy-current sensing technology to measure shaft displacement without physical contact between the probe tip and rotating shaft surface.

Q: What is the thread specification of this proximity probe?
A: The probe uses an M10 x 1 thread configuration with a 50 mm overall case length and 0 mm unthreaded length option.

Q: Does this model include agency approval certification?
A: No. The 330104-00-05-05-01-00 configuration does not include an agency approval option.

Field Installation Guidelines

Install the probe with correct mechanical alignment to maintain accurate shaft displacement measurement. Ensure the M10 x 1 threaded section engages properly with the mounting bracket or probe holder.

Route the standard cable away from high-current conductors and strong electromagnetic interference sources. Use proper cable support to prevent excessive mechanical stress on the miniature coaxial ClickLoc connector.

Connect the probe to the compatible Bently Nevada monitoring interface and verify the gap voltage before commissioning. The installation team should confirm probe clearance, signal polarity, and shielding continuity according to the applicable machinery monitoring system requirements.
