Keterangan
Bently Nevada 330101-00-28-10-02-00 3300 XL 8 mm Probe
Configured for proximity measurement in turbomachinery protection systems, the Bently Nevada 330101-00-28-10-02-00 (3300 XL 8 mm Probe) provides direct physical displacement transduction via eddy-current sensing within the 3300 monitoring network.
Hardware Specifications
Parameter
Specification
Brand
Bently Nevada
Model
330101-00-28-10-02-00
Origin
USA
Weight
0.15 kg
Dimensions
20.5 cm x 22.4 cm x 3.3 cm
Operating Temp
-35 degC to +120 degC
Power Consumption
Passive sensor; no external power
Thread Type
3/8-24 UNF
Unthreaded Length
0.0 in
Overall Case Length
2.8 in
Total Length
1.0 m (3.3 ft)
Connector Type
Miniature coaxial ClickLoc connector, standard cable
Agency Approval
Not required
Eddy-Current Probe Scaling & Gap Voltage Validation
The probe operates on eddy-current inductive scaling with a linear range defined by the target material’s electromagnetic properties. For optimal rotor dynamics measurement accuracy, maintain a gap voltage near -10 VDC at installation. Cross-talk suppression is achieved through precision shielding and controlled cable routing to minimize capacitive coupling between adjacent probes.
Frequently Asked Questions
Q: Can this probe be hot-swapped in an energized system?
A: No. Always de-energize the monitoring module before connecting or disconnecting the probe to prevent transient voltage damage.
Q: What is the effect of incorrect unthreaded length installation?
A: Improper positioning may shift the probe outside its calibrated linear range, reducing measurement accuracy and risking signal saturation.
Q: Does the miniature coaxial ClickLoc connector require torque specification during mating?
A: Yes. Finger-tighten only; over-torquing can deform the connector interface and degrade RF shielding performance.
Field Installation Guidelines
Mount the probe using the 3/8-24 UNF thread, ensuring full engagement without inducing mechanical stress on the case. Maintain proper standoff from the rotating surface within the specified gap range. Route the cable away from high-voltage conductors and secure it with non-metallic clamps to preserve signal integrity. Terminate the shield at the monitoring system ground point to control EMI ingress.
