Sensor dan probe menyediakan pemantauan yang akurat untuk peralatan industri. Produk kami mencakup probe getaran, jarak, dan perpindahan dari produsen terkemuka. Kami menyediakan model yang masih ada maupun yang sudah dihentikan produksinya dengan dukungan global yang tepercaya.
Sensor dan Probe
-
Bently Nevada 330878-51-05 | 3300 XL 50 mm Proximitor Sensor | Bently Nevada
Bently Nevada 330878-51-05 3300 XL 50 mm Proximitor Sensor Configured for eddy-current proximity signal conditioning in the Bently Nevada 3300 XL monitoring system, the Bently Nevada 330878-51-05 (330878 Proximitor Sensor) provides direct electrical signal conversion between the proximity probe assembly and the connected monitoring channel. The module is configured for a 5.0 m system length with DIN rail mounting and multiple agency approvals. Suffix Breakdown & Model Matrix The supplied documentation identifies 330878-51-05 as a fixed ordering model. No official suffix decoding beyond the documented configuration is provided. Therefore, no additional suffix interpretation is included. Hardware Specifications Parameter Specification Model 330878-51-05 Brand Bently Nevada Product Type 3300 XL 50 mm Proximitor Sensor Origin USA Shipment Location Xiamen, China Weight 0.2 kg Dimensions 8.8 x 3.5 x 7 cm (estimated shipping size) Mounting DIN mount System Length 5 m including extension cable Total System Length Option 5.0 m (16.4 ft) Output Resistance 50 Ohm Housing Material A380 aluminum Agency Approval Multiple Approvals Tariff Code 8537101190 Operating Temp Not specified Power Consumption Not specified Gap Voltage Validation and Probe Scaling The 3300 XL Proximitor Sensor is designed for operation with the corresponding eddy-current probe system using the specified system cable length. During commissioning, gap voltage should be verified against the installation target specified by the applicable Bently Nevada calibration procedure. For shaft vibration measurements, probe scaling accuracy depends on matching the Proximitor Sensor, extension cable, and proximity probe as a calibrated system. Mixing components with different calibrated system lengths can introduce measurement error. Frequently Asked Questions Q: Can this Proximitor Sensor be exchanged without recalibrating the monitoring channel?A: Replacement should use the identical model and configured system length. After installation, gap voltage and probe response should be verified according to the equipment commissioning procedure. Q: Can extension cables with different system lengths be connected to this unit?A: No. The Proximitor Sensor is calibrated for a defined total system length. Using an unmatched extension cable changes the probe system characteristics and measurement scaling. Q: Is hot swapping recommended during machine operation?A: The available documentation does not specify hot-swap capability. Replacement should follow the shutdown and maintenance procedure established for the connected monitoring system. Field Installation Guidelines Mount the sensor securely on a DIN rail with adequate mechanical support. Install only with the specified compatible proximity probe and extension cable to maintain calibrated system performance. Route probe cables separately from high-power conductors to minimize electromagnetic coupling. Ground cable shields according to the system grounding practice to reduce electrical noise and prevent ground loops. Verify probe gap voltage after installation before returning the monitored machine to service. Inspect cable connectors and locking hardware to ensure proper mechanical engagement before energizing the monitoring channel.
$200.00 $100.00
-
Bently Nevada Bently Nevada 285691-01 3300 XL Proximitor Sensor Module
Bently Nevada 285691-01 3300 XL Proximitor Sensor Module Configured for conversion of eddy-current proximity probe signals into calibrated displacement and vibration data within 3300 XL monitoring systems, the Bently Nevada 285691-01 (285691-01 Proximitor Sensor Module) provides direct electrical signal conditioning for shaft position measurement across standardized TSI input channels. Suffix Breakdown & Model Matrix The 285691-01 is a single defined orderable configuration within the 3300 XL Proximitor Sensor family. No validated sub-variant segmentation or hardware option matrix is defined in the provided dataset. Functional behavior is determined by external probe selection and system-level configuration parameters. Hardware Specifications Parameter Specification Model 285691-01 Brand Bently Nevada Weight ~0.2 kg Dimensions 76 x 25 x 25 mm Operating Temp -35 deg C to +100 deg C Power Consumption Not specified Measurement Range 2 mm to 80 mm (probe dependent) Linear Range 0.25 mm to 2.0 mm typical Accuracy ±0.25 percent of full scale Frequency Response DC to 10 kHz Input 3300 XL proximity probe compatible Output Sensitivity -200 mV/mil (7.87 mV/um) Power Supply -24 VDC nominal Humidity Up to 95 percent non-condensing Compliance API 670, CE, UL, CSA, RoHS Bently Nevada Eddy-Current Signal Conditioning and Cross-Talk Suppression The module performs eddy-current probe impedance conversion into linearized displacement voltage output using calibrated scaling constants defined for the 3300 XL architecture. Gap-based voltage reference tracking is maintained for shaft centerline measurement consistency. Cross-talk suppression is implemented through internal shielding geometry and grounded reference design, minimizing electrical coupling between adjacent measurement channels under multi-probe configurations. The signal path supports DC to 10 kHz bandwidth for both static position and dynamic vibration extraction. Frequently Asked Questions (FAQ) Q: Is the 285691-01 compatible with non-3300 XL probe systems?A: No. Input conditioning is calibrated for 3300 XL probe electrical characteristics. Mismatched impedance will result in non-linear scaling. Q: Does the module require external signal conditioning before monitoring input?A: No external conditioning is required. The module outputs a direct proportional voltage signal suitable for monitoring system acquisition. Q: What is the behavior under unstable -24 VDC supply conditions?A: Output accuracy is maintained only within nominal supply tolerance. Deviation outside specified limits may introduce scaling drift or reduced measurement stability. Field Installation Guidelines Install the module inside a grounded metallic enclosure to maintain shielding integrity for eddy-current signal paths. Maintain separation between probe wiring and high-voltage switching conductors to reduce electromagnetic interference. Use twisted shielded cables with single-point grounding at the monitoring system end only. Ensure correct routing without tight bends to avoid impedance variation in probe extension lines. Verify stable -24 VDC supply polarity and continuity prior to system energization.
$200.00 $100.00
-
Bently Nevada Bently Nevada 24583-04 3300 XL Proximitor Sensor
Bently Nevada 24583-04 3300 XL Proximitor Sensor Configured for conversion of eddy-current proximity probe signals into calibrated displacement and vibration outputs in 3300 XL monitoring architectures, the Bently Nevada 24583-04 (24583-04 Proximitor Sensor) provides direct electrical signal conditioning and scaling for shaft position measurement within the 3300 XL instrumentation chain. Suffix Breakdown & Model Matrix The 24583-04 is a single defined orderable sensor identifier within the 3300 XL Proximitor Sensor family. No validated functional segmentation or suffix-based hardware partition is specified in the provided dataset. System behavior is determined by probe type selection and external monitoring configuration parameters. Hardware Specifications Parameter Specification Model 24583-04 Brand Bently Nevada Weight 0.2 kg Dimensions Approx. 76 x 25 x 25 mm Operating Temp -35 deg C to +100 deg C Measurement Range 2 mm to 80 mm (probe dependent) Linear Range 0.25 mm to 2.0 mm typical Accuracy ±0.25 percent of full scale Frequency Response DC to 10 kHz Input 3300 XL proximity probe compatible Output Sensitivity -200 mV/mil (7.87 mV/um) Power Supply -24 VDC nominal Humidity Up to 95 percent non-condensing Compliance API 670, CE, UL, CSA, RoHS Bently Nevada Eddy-Current Probe Scaling and Cross-Talk Suppression The 24583-04 implements eddy-current signal linearization for shaft displacement conversion based on calibrated probe gap-voltage response characteristics. Output scaling is referenced to standardized -200 mV/mil conversion factors used in the 3300 XL system architecture. Cross-talk suppression is implemented through internal shielding geometry and differential reference handling to reduce channel interaction in multi-probe installations. Signal integrity is maintained across DC to 10 kHz bandwidth for both static position and dynamic vibration extraction. Frequently Asked Questions (FAQ) Q: Can the 24583-04 operate with non-3300 XL proximity probes?A: No. The input conditioning network is calibrated for 3300 XL probe electrical characteristics. Non-matching probe impedance results in non-linear displacement scaling. Q: Does the sensor require external signal conditioning modules?A: No external conditioning is required. The device provides direct proportional voltage output suitable for monitoring system input channels. Q: What happens if the -24 VDC supply deviates from nominal range?A: Output scaling integrity is maintained only within specified supply tolerance. Deviation outside design range may introduce linearity drift or reduced measurement stability. Field Installation Guidelines Install the sensor in a grounded metallic enclosure to maintain shielding integrity of eddy-current measurement circuits. Keep probe signal wiring separated from high-voltage or switching conductors to reduce electromagnetic coupling. Use twisted shielded cable with single-point grounding at the monitoring system end. Avoid sharp bends in probe extension cables to maintain impedance stability. Verify correct polarity and stability of the -24 VDC supply prior to energization of the measurement loop.
$200.00 $100.00
-
Bently Nevada Bently Nevada 24583-03 3300 XL Proximitor Sensor
Bently Nevada 24583-03 3300 XL Proximitor Sensor The Bently Nevada 24583-03, also cataloged as the 3300 XL Proximitor Sensor displacement monitoring module, operates as a dedicated hardware component for conversion of eddy-current probe signals into calibrated vibration and shaft position data within 3300 XL monitoring systems. Hardware Specifications Parameter Specification Model 24583-03 Brand Bently Nevada Weight 0.2 kg Dimensions 76 x 25 x 25 mm Operating Temp -35 deg C to +100 deg C Power Consumption Not specified Measurement Range 2 mm to 80 mm (probe dependent) Linear Range 0.25 mm to 2.0 mm typical Accuracy ±0.25 percent of full scale Frequency Response DC to 10 kHz Input Type 3300 XL proximity probe compatible Output -200 mV/mil (7.87 mV/um) Power Supply -24 VDC nominal Humidity Up to 95 percent non-condensing Compliance API 670, CE, UL, CSA, RoHS Bently Nevada Eddy-Current Transduction and Rotor Dynamics Interface The 24583-03 processes eddy-current probe impedance variation into linear displacement voltage conversion using calibrated scaling coefficients defined for the 3300 XL probe family. Probe gap voltage reference behavior is tied to baseline air-gap conditions for shaft centerline tracking, with sensitivity mapping maintained across the defined linear operating window. Rotor dynamics evaluation is derived from DC-coupled displacement signals supporting low-frequency orbit analysis and synchronous vibration extraction. Cross-channel electrical interference is mitigated through internal shielding and grounded reference topology within the sensor interface stage. Frequently Asked Questions (FAQ) Q: Is the 24583-03 compatible with non-3300 XL proximity probes?A: No. The input conditioning network is calibrated for 3300 XL probe electrical characteristics. Non-matching probe impedance may result in non-linear output scaling. Q: Does the sensor output require external signal conditioning before monitoring systems?A: No additional conditioning is required. The device provides direct proportional voltage output (-200 mV/mil) suitable for monitoring system input channels. Q: How is signal stability affected during power supply fluctuation on -24 VDC input?A: Internal regulation maintains signal scaling integrity within nominal -24 VDC operation. Deviations outside tolerance may affect output linearity. Field Installation Guidelines Install the module in a grounded metallic enclosure to maintain signal shielding integrity for eddy-current measurement circuits. Maintain separation between probe signal wiring and high-voltage or switching conductors to reduce electromagnetic coupling. Use twisted, shielded cable for probe connections, with single-point shield termination at the monitoring system end. Ensure probe extension cables are routed without sharp bends to avoid impedance discontinuities. Verify correct polarity of the -24 VDC supply prior to system energization.
$200.00 $100.00
-
Bently Nevada 330850-50-CN | Bently Nevada | Sensor Proximitor 3300 XL 25 mm
Sensor Proximitor Bently Nevada 330850-50-CN Bently Nevada 330850-50-CN, juga dikatalogkan sebagai Sensor Proximitor 3300 XL 25 mm, beroperasi sebagai komponen perangkat keras khusus untuk pengkondisian sinyal arus eddy dan pengukuran perpindahan dalam sistem transduser kedekatan 3300 XL. Dikonfigurasi untuk konversi sinyal dari variasi celah probe menjadi keluaran tegangan proporsional, Bently Nevada 330850-50-CN (Sensor Proximitor 3300 XL 25 mm) menyediakan eksekusi listrik langsung untuk pemantauan celah rotor-ke-casing. Spesifikasi Perangkat Keras Parameter Spesifikasi ModelMerek Bently Nevada 330850-50-CN Asal AS Berat 0,2 kg Dimensi 8,8 x 3,5 x 7 cm (ukuran pengiriman) Suhu Operasi T/A Konsumsi Daya T/A Panjang Sistem 5,0 m (16,4 kaki) Resistansi Keluaran 50 W Faktor Skala Rata-rata 0,787 V/mm Bahan Probe Baja tahan karat AISI 304 Tipe Produk Sensor Proximitor 3300 XL 25 mm Pengkondisian Sinyal Arus Eddy dan Skala Tegangan Celah 330850-50-CN memproses umpan balik probe arus eddy dengan mengubah modulasi celah probe-target menjadi respons tegangan terkalibrasi yang ditentukan oleh faktor skalanya 0,787 V/mm. Operasi sistem selaras dengan praktik validasi referensi celah -10 VDC yang digunakan dalam loop kalibrasi transduser kedekatan. Linearitas sinyal dipertahankan melalui pencocokan impedansi yang terkontrol pada antarmuka proximitor, mendukung pelacakan perpindahan dinamika rotor. Penekanan crosstalk diimplementasikan pada tingkat antarmuka probe-kabel untuk menjaga integritas isolasi saluran di bawah instalasi multi-probe. Pertanyaan yang Sering Diajukan Q: Apakah 330850-50-CN mendukung penggantian hot-swap langsung di saluran kedekatan aktif?A: Penggantian memerlukan isolasi daya sistem. Proximitor tidak dirancang untuk hot-swap langsung di bawah kondisi bias probe berenergi. Q: Antarmuka listrik apa yang mengatur jalur sinyal probe-ke-proximitor?A: Sistem ini menggunakan antarmuka induktif arus eddy dengan penskalaan tegangan yang proporsional dengan perpindahan celah, direferensikan terhadap sirkuit eksitasi bias internal. Q: Bisakah beberapa saluran proximitor beroperasi berdekatan tanpa interferensi sinyal?A: Pemisahan saluran dipertahankan melalui desain penekanan crosstalk, tetapi pemisahan perutean fisik dan penghentian pelindung tetap wajib. Panduan Instalasi Lapangan Perutean probe dan kabel ekstensi harus mempertahankan pelindung kontinu dari kepala probe ke terminal masukan proximitor. Penghentian pelindung harus di-ground pada satu titik referensi sistem untuk menghindari pembentukan loop ground. Radius lentur kabel harus dikontrol untuk mencegah diskontinuitas impedansi sepanjang panjang sistem 3300 XL. Instalasi harus memastikan isolasi mekanis rumah probe untuk menghindari distorsi sinyal yang disebabkan oleh getaran. Semua koneksi harus diverifikasi untuk impedansi yang stabil sebelum memberi energi pada saluran pemantauan.
$200.00 $100.00
-
Bently Nevada Sensor Proximitor 330980-70-00 | Bently Nevada
Sensor Proximitor Bently Nevada 330980-70-00 Bently Nevada 330980-70-00 yang juga dikatalogkan sebagai Sensor Proximitor 3300 XL NSv beroperasi sebagai komponen perangkat keras khusus untuk konversi sinyal perpindahan arus eddy dalam arsitektur pengukuran kedekatan 3300 XL NSv. Rincian Akhiran & Matriks Model 70: Konfigurasi panjang sistem 7.0 m (23.0 kaki) 00: opsi tanpa persyaratan persetujuan agensiTidak ada dekode struktural tambahan yang ditentukan di luar kode konfigurasi pabrik. Spesifikasi Perangkat Keras Parameter Spesifikasi Model / Merek Bently Nevada 330980-70-00 Asal Amerika Serikat Berat 0,26 kg Dimensi 8 x 6,1 x 6,5 cm (amplop pengiriman) Suhu Operasional Tidak ditentukan (lihat manual instalasi sistem) Konsumsi Daya Tidak ditentukan (perangkat pengondisian sinyal pasif) Jenis Sensor Sensor Proximitor 3300 XL NSv Panjang Sistem 7.0 m (23.0 kaki) Resistansi Output 50 ohm Bahan Casing Aluminium A380 Bahan Casing Probe Baja tahan karat AISI 304 Jenis Pemasangan Pemasangan panel Pengondisian Sinyal Arus Eddy dan Validasi Tegangan Celah Sensor Proximitor 3300 XL NSv menerapkan penskalaan probe arus eddy untuk pengukuran perpindahan poros non-kontak. Pengondisian sinyal dilakukan melalui tahap osilator-demodulator yang dikalibrasi yang dirancang untuk menjaga respons linier di seluruh celah udara probe-ke-target. Validasi tegangan celah direferensikan terhadap wilayah bias negatif nominal (wilayah target -10 VDC tipikal dalam sistem transduser kedekatan). Loop pengondisian menjaga stabilitas amplitudo di bawah dinamika rotor variabel, memastikan output demodulasi yang konsisten sebanding dengan posisi radial poros. Penekanan crosstalk diimplementasikan melalui kontinuitas pelindung dan pencocokan impedansi terkontrol di seluruh tahap output 50 ohm. Pertanyaan yang Sering Diajukan T: Bisakah sensor beroperasi dengan panjang kabel probe campuran?J: Hanya kombinasi kabel probe dan kabel ekstensi 3300 XL NSv yang memenuhi syarat sistem yang didukung. Impedansi yang tidak cocok mengubah kemiringan kalibrasi dan linearitas celah. T: Apakah tahap output mendukung penggantian hot-swap?J: Sensor proximitor tidak dirancang untuk penyisipan hot-swap yang bertenaga. Isolasi daya sistem diperlukan untuk menghindari pergeseran offset transien. T: Apa efek kesalahan grounding terhadap stabilitas sinyal?J: Grounding yang tidak tepat menyebabkan kopling kebisingan arus eddy dan mendistorsi linearitas tegangan celah, menghasilkan pembacaan perpindahan yang tidak stabil. Pedoman Pemasangan di Lapangan Sensor proximitor harus dipasang menggunakan fiksasi panel-mount dengan torsi terkontrol untuk menghindari deformasi casing. Perutean kabel harus menjaga pemisahan dari konduktor tegangan tinggi untuk meminimalkan kopling elektromagnetik ke dalam loop output 50 ohm. Penghentian pelindung harus dilakukan pada referensi tanah satu titik untuk menghindari pembentukan loop tanah. Sambungan ekstensi probe harus diamankan secara mekanis dan diverifikasi kontinuitasnya sebelum sistem diberi energi. Pertahankan kalibrasi celah udara yang konsisten menggunakan permukaan target yang ditentukan pabrikan dan hindari interferensi pemasangan feromagnetik di dalam bidang penginderaan.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330980-51-00 Sensor Proximitor
Sensor Proximitor Bently Nevada 330980-51-00 Dikonfigurasi untuk konversi sinyal kedekatan dalam sistem Sensor Proximitor Bently Nevada 3300 XL NSv, Bently Nevada 330980-51-00 (Sensor Proximitor 330980) menyediakan eksekusi fisik/elektrik langsung untuk pengukuran perpindahan berbasis arus-eddy dalam rantai sinyal transduser Bently Nevada. Rincian Akhiran & Matriks Model 51: Panjang sistem 5,0 m (16,4 kaki), konfigurasi pemasangan rel DIN 00: Tidak ada opsi persetujuan lembaga yang diperlukan Spesifikasi Perangkat Keras Parameter Spesifikasi Model Bently Nevada 330980-51-00 Merek Bently Nevada Asal AS Berat 0,2 kg Dimensi 8,13 cm x 6,12 cm x 6,35 cm Panjang Sistem 5,0 m (16,4 kaki) Resistansi Keluaran 50 ohm Faktor Skala Inkremental 7,87 V/mm (200 mV/mil) Bahan Sensor Aluminium A380 Tipe Pemasangan Kompatibel dengan pemasangan rel DIN / panel Karakteristik Transduksi Arus-Eddy Bently Nevada 330980-51-00 beroperasi sebagai bagian dari rantai pengukuran arus-eddy 3300 XL NSv, mengimplementasikan konversi tegangan celah yang terkalibrasi untuk pelacakan getaran radial dan perpindahan poros. Tahap pengkondisian sinyal mendukung penyelarasan penskalaan standar pada 7,87 V/mm, memastikan terjemahan yang konsisten dari variasi celah probe ke keluaran tegangan dalam loop antarmuka proximitor. Peredam silang diimplementasikan melalui pelindung internal yang dioptimalkan dan pencocokan impedansi (tahap keluaran 50 ohm), mengurangi kerentanan interferensi dalam lingkungan pemantauan mesin kepadatan tinggi. Arsitektur proximitor mendukung perilaku validasi tegangan celah yang stabil dalam sistem penskalaan referensi -10 VDC tipikal yang digunakan di seluruh rakitan probe kedekatan Bently Nevada. Pertanyaan yang Sering Diajukan T: Apakah 330980-51-00 mendukung instalasi hot-swap?J: Modul ini tidak dirancang untuk penyisipan hot-swap bertenaga. Pemutusan loop sinyal diperlukan sebelum penggantian untuk mencegah eksitasi transien pada tahap keluaran proximitor. T: Apa dampak panjang kabel terhadap akurasi penskalaan sinyal?J: Panjang sistem 5,0 m sesuai pabrikan. Penyimpangan panjang ekstensi atau ketidaksesuaian impedansi konektor dapat memengaruhi linearitas arus-eddy dan akurasi kalibrasi. T: Bisakah keluaran 50 ohm dihubungkan langsung ke input analog PLC?J: Sambungan langsung tidak disarankan tanpa pengkondisian sinyal yang tepat atau pencocokan impedansi input untuk mempertahankan karakteristik transfer tegangan linier. Panduan Instalasi Lapangan Pertahankan grounding pelindung berkelanjutan pada satu titik referensi tanah untuk mencegah arus loop tanah. Pastikan stabilitas pemasangan rel DIN dengan keterlibatan kursi mekanis penuh untuk menghindari injeksi kebisingan perpindahan mikro. Routing kabel sensor secara terpisah dari saluran daya penggerak atau sakelar frekuensi tinggi untuk mengurangi kopling elektromagnetik. Hindari tekukan kabel yang tajam; pertahankan radius tekukan minimum yang konsisten dengan praktik pengkabelan instrumentasi industri. Verifikasi torsi konektor dan integritas kontak pada titik terminasi proximitor dan probe sebelum sistem diberi energi.
$200.00 $100.00
-
Bently Nevada Sensor Proximitor Bently Nevada 330850-91-05
Bently Nevada 330850-91-05 Proximitor Sensor Dikonfigurasi untuk konversi variasi celah probe arus eddy menjadi tegangan analog terkondisi dalam arsitektur pemantauan 3300 XL, Bently Nevada 330850-91-05 (3300 XL 25 mm Proximitor Sensor) menyediakan pengkondisian sinyal listrik langsung untuk rantai pengukuran getaran dan perpindahan radial. Rincian Akhiran & Matriks Model Tidak ada dekomposisi akhiran yang diterbitkan secara eksplisit oleh produsen untuk 330850-91-05 yang disediakan dalam kumpulan data yang diberikan. Kode pemesanan direferensikan sebagai pengidentifikasi konfigurasi tingkat sistem dalam platform 3300 XL 25 mm Proximitor Sensor, terutama mendefinisikan panjang sistem dan opsi persetujuan. Spesifikasi Perangkat Keras Parameter Spesifikasi ModelMerek Bently Nevada 330850-91-05 Asal AS Berat 0,2 kg Dimensi 8,8 x 3,5 x 7 cm (ukuran pengiriman) Suhu Operasi -51 derajat C hingga +100 derajat C Suhu Penyimpanan -51 derajat C hingga +105 derajat C Panjang Sistem 9,0 m (29,5 kaki) Faktor Skala Rata-rata 0,787 V/mm (20 mV/mil) nominal Konsumsi Daya Tidak ditentukan Jenis Produk Sensor Proximitor (Kondisioner Sinyal Arus Eddy) Karakteristik Penskalaan Arus Eddy dan Validasi Tegangan Celah Sensor Proximitor 3300 XL 25 mm mengimplementasikan penskalaan transduksi arus eddy yang selaras dengan linearisasi celah probe-ke-target. Fungsi transfer keluaran direferensikan ke penskalaan sensitivitas nominal 0,787 V/mm, memungkinkan konversi perpindahan dari demodulasi pembawa frekuensi tinggi. Validasi tegangan celah selaras dengan perilaku referensi bias -10 VDC standar yang umum dalam sistem kedekatan Bently Nevada. Ini mendukung verifikasi wilayah operasi linier untuk kondisi jarak probe-ke-target di bawah gerakan poros statis dan dinamis. Peredam silang (cross-talk) dicapai melalui arsitektur kabel berpelindung dan perutean sinyal terkontrol impedansi, meminimalkan interferensi antara saluran getaran yang berdekatan dalam instalasi multi-probe. Integritas sinyal dinamika rotor dipertahankan melalui tahap demodulasi rendah derau yang dioptimalkan untuk pelacakan getaran poros kecepatan tinggi. Pertanyaan yang Sering Diajukan T: Apakah 330850-91-05 dapat di-hot-swap dalam sistem rak 3300 XL yang sedang berjalan?J: Modul ini tidak dirancang untuk penyisipan langsung. Isolasi daya diperlukan sebelum pemutusan rantai sensor untuk mencegah eksitasi transien sirkuit penggerak probe. T: Bagaimana perilaku kelistrikan antarmuka penskalaan keluaran?J: Keluaran adalah tegangan analog terkondisi yang sebanding dengan perpindahan celah, menggunakan faktor penskalaan nominal 0,787 V/mm di bawah kondisi kalibrasi standar. T: Apakah panjang sistem 9,0 m memengaruhi integritas sinyal?J: Panjang sistem menentukan batas perutean kabel probe. Penyimpangan berlebihan dari panjang nominal dapat menyebabkan redaman dan distorsi fasa dalam loop arus eddy. Panduan Instalasi Lapangan Pastikan pemisahan yang tepat antara kabel probe dan konduktor tegangan tinggi untuk meminimalkan kopling elektromagnetik. Pertahankan pembumian pelindung berkelanjutan pada satu titik referensi untuk menghindari arus loop tanah di jalur sinyal proximitor. Perutean kabel harus mematuhi spesifikasi radius tekuk minimum untuk mencegah variasi impedansi koaksial. Semua konektor harus dikencangkan sesuai standar retensi mekanis pabrikan untuk memastikan transmisi pembawa frekuensi tinggi yang stabil. Verifikasi kalibrasi celah probe menggunakan referensi poros statis sebelum commissioning. Hindari tekanan mekanis pada rakitan ujung probe selama pemasangan untuk mempertahankan karakteristik respons linier.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330850-51-05 3300 XL 25 mm Proximitor Sensor
Bently Nevada 330850-51-05 3300 XL 25 mm Proximitor Sensor Configured for eddy-current displacement signal conditioning in 3300 XL machinery monitoring networks, the Bently Nevada 330850-51-05 (3300 XL 25 mm Proximitor Sensor) provides direct physical/electrical execution. The module processes non-contact probe signals for shaft vibration and position measurement using calibrated scaling and gap voltage validation aligned with proximity transducer chain behavior. It is designed as an interface element between extension cable/probe assemblies and monitoring electronics. Suffix Breakdown & Model Matrix 330850: Proximitor Sensor base platform for 3300 XL 25 mm system 51: DIN rail mounting and system length configuration option 05: Multiple agency approval configuration variant 5.0 metres (16.4 feet): System length definition for probe + extension assembly integration Hardware Specifications Parameter Specification ModelBrand Bently Nevada 330850-51-05 Origin USA Weight 0.2 kg Dimensions 8.8 x 3.5 x 7 cm (estimated shipping size) OperatingTemp Not specified PowerConsumption Not specified Core Function Eddy-current probe signal conditioning System Length 5.0 m (16.4 ft) Input Type 3300 XL 25 mm non-contacting proximity probe + extension cable Output Resistance 50 Ohm Average Scale Factor 0.787 V/mm (20 mV/mil) nominal Eddy-Current Probe Scaling and Gap Voltage Validation Architecture The 3300 XL 25 mm Proximitor Sensor implements eddy-current transducer interface conditioning with calibrated transfer characteristics for gap displacement conversion. The signal path maintains scaling linearity through defined probe-to-surface spacing response, supporting gap voltage validation targeting negative DC bias regions typical of proximity probe systems. Cross-talk suppression is achieved through controlled impedance matching and shielding integrity across extension cable interfaces, minimizing signal distortion under multi-channel vibration monitoring topologies. Frequently Asked Questions Q1: Can the 330850-51-05 be hot-swapped during active monitoring operation?A: Hot-swap capability depends on system backplane implementation. The sensor itself does not provide internal hot-swap isolation; removal during energized probe operation may interrupt bias voltage continuity. Q2: What is the electrical interface limitation for probe cable length?A: The system is defined for a 5.0 m total probe + extension cable length. Exceeding configured length may alter scaling accuracy and reduce gap voltage linearity. Q3: Does the output resistance affect signal conditioning accuracy?A: The 50 Ohm output resistance is part of the conditioned signal path design and is matched to downstream monitoring input impedance to preserve waveform fidelity. Field Installation Guidelines Install the Proximitor Sensor on DIN rail with secure mechanical retention to minimize vibration-induced connector micro-movement. Maintain separation between probe signal wiring and high-voltage conductors to reduce electromagnetic coupling. Ensure cable shield termination is grounded at a single-point earth reference to avoid ground loop currents. Verify probe-to-sensor continuity before energizing the system to confirm valid gap voltage response within expected eddy-current operating range.
$200.00 $100.00
-
Bently Nevada 330850-50-00 3300 XL 25 mm Proximitor Sensor | Bently Nevada
Bently Nevada 330850-50-00 3300 XL 25 mm Proximitor Sensor TheBently Nevada 330850-50-00，also cataloged as the330850-50-00 Proximitor Sensor, operates as a dedicated hardware component for eddy-current displacement signal conditioning within the 3300 XL proximity measurement system. Eddy-Current Scaling and Gap Voltage Validation (-10 VDC Targets) The 3300 XL 25 mm Proximitor architecture processes probe-induced eddy-current variations into proportional voltage outputs used for radial vibration and axial position tracking. The signal conditioning stage maintains calibrated transfer characteristics referenced to gap voltage behavior centered around -10 VDC nominal operating region. Cross-channel interaction is minimized through internal filtering topology to support stable rotor-dynamic measurement chains. SuffixBreakdown&ModelMatrix No officially published internal suffix segmentation or functional matrix breakdown is provided for 330850-50-00. Configuration is defined at system assembly level within the 3300 XL probe + extension cable + proximitor chain. HardwareSpecifications Parameter Specification Model Brand Bently Nevada 330850-50-00 Origin USA Weight 0.22 kg Dimensions 8 x 6 x 6.5 cm (shipping size) OperatingTemp N/A PowerConsumption N/A System Length 5.0 m (16.4 ft) system length Output Resistance 50 W Average Scale Factor 0.787 V/mm (20 mV/mil) nominal Bently Nevada Eddy-Current Signal Conditioning Characteristics The 3300 XL proximitor signal path is designed for eddy-current probe linearization and sensitivity scaling. Probe-to-target air gap variations are converted into analog voltage output with defined scale factor behavior. The conditioning stage is optimized for stable amplitude response under rotating machinery shaft dynamics, with suppression of parasitic coupling between adjacent measurement channels in multi-probe installations. Frequently Asked Questions Q: Can the 330850-50-00 be hot-swapped during operation?A: The proximitor is typically part of a wired measurement chain. Replacement requires signal loop isolation and removal of excitation from the probe circuit. Q: Does the system support direct backplane communication?A: The module functions as an analog signal conditioning unit and does not provide digital backplane protocol communication. Q: What limits signal stability in long extension cable configurations?A: Cable capacitance, connector integrity, and shielding continuity directly affect eddy-current signal amplitude and phase stability. Field Installation Guidelines Ensure probe extension cables maintain continuous shielding with single-point grounding at the monitoring system cabinet. Avoid routing proximity signal cables parallel to high-voltage conductors to reduce induced noise coupling. Maintain recommended connector torque to preserve impedance stability across the probe-proximitor interface. Verify air gap calibration using standard target materials prior to system commissioning.
$200.00 $100.00
-
Bently Nevada 330780-91-00 3300 XL 11MM Proximitor Sensor | Bently Nevada
Bently Nevada 330780-91-00 3300 XL 11MM Proximitor Sensor Configured for signal conditioning of eddy-current proximity probe measurements in Bently Nevada 3300 XL monitoring architecture, the Bently Nevada 330780-91-00 (3300 XL 11mm Proximity Sensor) provides direct physical/electrical execution. The module conditions input from a single non-contacting 3300 XL 11 mm proximity probe and extension cable, converting displacement-dependent gap variation into a proportional voltage output for machine condition monitoring. Internal scaling is aligned with eddy-current probe linearization requirements, with sensitivity characteristics maintained under supply variation constraints. Hardware Specifications Parameter Specification Model 330780-91-00 Brand Bently Nevada Origin USA Weight 0.2 to 0.255 kg Dimensions 8.8 x 3.6 x 7.1 cm (estimated shipping size) OperatingTemp -35 degC to +85 degC StorageTemp -51 degC to +100 degC PowerConsumption -17.5 Vdc to -26 Vdc, 12 mA max Input Type 3300 XL 11 mm proximity probe + extension cable Output Resistance 50 ohm Supply Sensitivity < 2 mV output change per 1 V input variation System Length Option 9.0 m (29.5 ft), DIN mount (option 91) Bently Nevada Eddy-Current Signal Conditioning Behavior The 330780-91-00 integrates into rotor dynamics measurement chains where eddy-current probe gap voltage is mapped into calibrated displacement signals. Signal linearity is dependent on stable -23.5 Vdc to -26 Vdc operation window, where deviation can reduce effective linear range. Cross-talk suppression is implemented through internal shielding reference design, minimizing induced noise between adjacent probe channels in multi-channel TSI installations. The proximitor stage ensures stable conversion of high-frequency probe oscillation into usable DC output proportional to shaft position. Frequently Asked Questions Q: Can the 330780-91-00 operate outside -23.5 Vdc supply range?A: Operation is possible, but reduced linear measurement range is observed due to internal scaling deviation. Q: Does the module support multiple proximity probes simultaneously?A: No. The input stage is designed for a single 3300 XL 11 mm probe and corresponding extension cable only. Q: What is the effect of supply voltage fluctuation on output signal?A: Output variation is limited to less than 2 mV per 1 V supply change under specified operating conditions. Field Installation Guidelines Install the proximitor module on a DIN rail mount structure with secure mechanical grounding to minimize EMI coupling. Maintain separation between probe signal cabling and high-power switching conductors to reduce induced noise. Ensure coaxial shielding continuity from probe to proximitor input termination without interruption. Verify correct negative DC supply polarity before energization. Cable routing should follow fixed tray segregation rules for low-level analog signals in TSI systems.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330180-X2-05 Proximitor Sensor
Bently Nevada 330180-X2-05 Proximitor Sensor Configured for eddy-current based proximity signal conversion in the 3300 XL Proximitor system, the Bently Nevada 330180-X2-05 (330180-X2-05 Proximitor Sensor) provides direct physical-to-electrical translation of probe gap variation into buffered voltage output for rotational machinery monitoring channels. Suffix Breakdown & Model Matrix 330180: Proximitor Sensor base series designation X2: System configuration variant identifier (mechanical/electrical option set) 05: Agency approval package (CSA, ATEX, IECEx certified configuration) Hardware Specifications Parameter Specification ModelBrand Bently Nevada 330180-X2-05 Origin USA Weight 0.25 kg Dimensions 7.8 x 3 x 6.2 cm (shipping size) OperatingTemp Not specified in provided data PowerConsumption Not specified (system powered via monitoring rack supply) ProductType Proximitor Sensor System Compatibility 3300 XL Proximity Measurement System Output Function Buffered gap voltage signal conditioning Eddy-Current Proximitor Signal Conditioning Behavior The 330180-X2-05 implements eddy-current probe signal linearization through controlled demodulation of high-frequency carrier excitation. The conversion stage maps probe-to-target gap variation into proportional DC voltage used by vibration and position channels. Cross-talk suppression is implemented through internal shielding layout and differential signal routing, reducing coupling between adjacent probe channels in multi-slot rack configurations. The device maintains stable scaling alignment with calibrated gap voltage validation targets in the negative DC reference region typically associated with proximity transducer systems. Frequently Asked Questions Q: Can the 330180-X2-05 be hot-swapped during system operation?A: Hot-swap is not supported at the sensor signal conditioning level. Removal requires channel isolation and system rack power safety procedures. Q: Does the module require external calibration after replacement?A: Calibration verification is required at system level using matched proximity probe and extension cable sets. The sensor itself does not store calibration constants. Q: Is signal output affected by adjacent channel installation density?A: Channel-to-channel interference is mitigated by internal shielding design, but installation spacing and cable routing still influence noise performance. Field Installation Guidelines Mount the sensor in a controlled rack environment with stable grounding to the system chassis reference plane. Ensure proximity probe extension cables are routed with separation from high-energy conductors to minimize induced noise coupling. Shield termination must be bonded at a single-point ground reference to prevent ground loop formation. Avoid sharp bends in probe wiring that may alter impedance characteristics. Maintain connector torque within standard industrial fastener engagement practices for signal integrity retention.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330180-91-00 Proximitor Sensor Module
Bently Nevada 330180-91-00 Proximitor Sensor Module Configured for eddy-current displacement signal conditioning in Bently Nevada 3300 XL machinery monitoring systems, the Bently Nevada 330180-91-00 (330180-X0-00 Proximitor Sensor) provides direct electrical conversion of probe gap variation into conditioned voltage output for vibration and position measurement loops. Suffix Breakdown & Model Matrix No official or structured suffix segmentation data is provided for 330180-91-00 within the supplied documentation. The model is treated as a fixed-order configuration within the 3300 XL Proximitor Sensor family. Hardware Specifications Parameter Specification Model Brand Bently Nevada 330180-91-00 Origin USA Weight 0.24 kg Dimensions 8 cm x 6 cm x 6.3 cm (shipping) Operating Temp -52 degC to +100 degC Power Consumption Not specified System Compatibility 3300 XL proximity probe systems (5 mm / 8 mm probes) Mounting Type Panel / DIN mount System Length Up to 9.0 m probe extension system Eddy Current Scaling and Gap Voltage Validation Characteristics The 330180 series implements eddy-current probe signal linearization for displacement transduction across 5 mm and 8 mm probe geometries. Internal conditioning circuitry is designed to maintain calibrated transfer characteristics between probe tip gap variation and output voltage scaling. Gap voltage validation is aligned with standardized -10 VDC reference limits used in Bently Nevada proximity monitoring chains, enabling stable zero-gap reference tracking and linear operating region verification during rotor-to-probe clearance transitions. Signal integrity is maintained under long cable runs via cross-talk suppression design rules embedded in the 3300 XL architecture. Frequently Asked Questions Q: Can the 330180-91-00 operate with both 5 mm and 8 mm probes?A: Yes. The module is designed for compatibility with both 5 mm and 8 mm proximity probe systems within the 3300 XL architecture. Q: Does the sensor require external power regulation beyond 24 VDC supply?A: The device operates from a nominal 24 VDC input; no additional external regulation module is specified in the provided documentation. Q: What is the maximum supported system cable length?A: The configured system length is specified up to 9.0 m for probe and extension cable integration. Field Installation Guidelines Ensure the proximitor sensor is mounted using DIN or panel mounting hardware with secure mechanical fixation to minimize vibration-induced measurement drift. Maintain proper separation between probe extension cables and high-power conductors to reduce electromagnetic coupling effects. Shield termination should be grounded at a single point to avoid ground loop formation within the 3300 XL signal chain. During installation, verify probe gap calibration stability across the full thermal operating range from -52 degC to +100 degC before commissioning.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330180-51-00 3300 XL Proximitor Sensor
Bently Nevada 330180-51-00 3300 XL Proximitor Sensor The Bently Nevada 330180-51-00, also cataloged as the 3300 XL Proximity Sensor, operates as a dedicated hardware component for converting eddy-current probe displacement signals into proportional voltage targets within 3300 and 3300 XL Machinery Monitoring System platforms. Hardware Specifications Parameter Specification Model 330180-51-00 Brand Bently Nevada Origin USA Weight 0.2 kg Dimensions 8.8 x 3.5 x 7 cm Total Length and Mounting Option 5.0 meters (16.4 feet) system length, DIN mount Agency Approval Option 00 Not required Output Resistance 50 Ohm Supply Voltage 24 VDC Scale Factor 7.87 V/mm (200 mV/mil) Probe Compatibility 5 mm and 8 mm eddy-current probes Tariff Code 8537101190 Eddy-Current Probe Scaling and Cross-Talk Suppression The 330180-51-00 sensor achieves precise eddy-current probe scaling by generating a high-frequency radio frequency (RF) signal to excite the attached 5 mm or 8 mm probe tip. The resulting electromagnetic field interacts with the target rotor dynamic surfaces, modifying the internal oscillator amplitude. The device decodes these variations to deliver a linear voltage output proportional to the gap distance, calibrated at a standard 7.87 V/mm scale factor. To maintain target signal integrity across multi-channel turbomachinery trains, the physical packaging integrates cross-talk suppression and radio frequency interference (RFI) immunity. This design allows high-density DIN-rail or panel-mount grouping inside fiberglass enclosures without signal degradation or the need for separate metallic isolation plates. Frequently Asked Questions Q: How is the gap voltage validation performed on this sensor? A: Gap voltage validation is performed by measuring the DC voltage output across the SIG and COM terminals using a digital multimeter. Under standard calibration conditions, a nominal -10 VDC target voltage corresponds to the midpoint of the linear range for the 3300 XL 5 mm and 8 mm probe systems. Q: Can this sensor be mounted alongside older Proximitor footprints? A: Yes. The underlying mechanical base supports dual configurations. It integrates a secure DIN-rail locking mechanism for high-density rail systems alongside a traditional 4-hole mounting footprint that matches older Bently Nevada Proximitor layouts, ensuring backward physical compatibility. Field Installation Guidelines Electrical Isolation: Ensure the integrated mounting base is properly locked onto the DIN rail or secured to the panel. The base provides 500 Vrms galvanic isolation from the frame, eliminating the requirement for external non-conductive isolator plates. Cable Routing Constraints: Maintain a physical separation between the Proximitor extension cables and high-voltage AC power lines to prevent electromagnetic coupling. Do not exceed the designated 5.0-meter total system length combination (probe plus extension cable) to avoid altering the calibrated scale factor. Coaxial Connector Torque: Hand-tighten the coaxial connections between the probe, extension cable, and the 330180-51-00 sensor. Do not use pliers or excessive mechanical torque, as this can deform the sub-miniature connectors and degrade the high-frequency RF path.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330180-50-CN 3300 XL Proximitor Sensor
Bently Nevada 330180-50-CN 3300 XL Proximitor Sensor The Bently Nevada 330180-50-CN, also cataloged as the 330180 Proximitor Sensor, operates as a dedicated hardware component for eddy-current signal conditioning within machinery monitoring systems. Suffix Breakdown & Model Matrix 50: 5.0 meters (16.4 feet) system length, panel mount configuration. CN: Country-specific agency approvals. Hardware Specifications Parameter Specification Model 330180-50-CN Brand Bently Nevada Origin USA Weight 0.22 kg Dimensions 8 x 6 x 6.5 cm Operating Temp -40 degC to +85 degC (-40 degF to +185 degF) Power Consumption Not specified Channels Single channel per module Frequency Response 0.5 Hz to 12 kHz (+/- 3 dB) Scale Factor 200 mV/mil Cable Length 5.0 meters LED Indicators Power (Green) Terminals Screw terminals (2.5 mm2) Tariff Code 8537101190 Eddy-Current Probe Scaling and Gap Voltage Validation The sensor provides precise eddy-current probe scaling, transforming physical shaft displacement into a proportional voltage signal for monitoring rotor dynamics. During commissioning, gap voltage validation is required to ensure the probe operates within its linear calibration range near the -10 VDC target. Proper physical isolation and structural positioning are necessary to ensure cross-talk suppression when multiple sensors are installed in close proximity. Frequently Asked Questions Q: What is the technical significance of the 200 mV/mil scale factor? A: It defines the sensor output sensitivity, where every 0.001 inch (1 mil) of physical movement by the target material produces a 200 mV change in the output voltage signal. Q: Can this sensor function with any cable or probe length? A: No. The internal circuitry is matched to a specific system length. This module requires a total physical length of 5.0 meters across the probe and extension cable to maintain its calibrated accuracy. Field Installation Guidelines Mount the unit onto a clean, flat panel surface using the integrated mounting holes. Terminate all field wiring inside the 2.5 mm2 screw terminals, ensuring no exposed copper strands remain outside the terminal block. Verify that the total combined length of the proximity probe and extension cable equals exactly 5.0 meters to prevent calibration drift. Ensure proper coaxial shielding and grounding protocols are followed to minimize high-frequency electrical noise interference.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330180-12-00 3300 XL Proximitor Sensor
Bently Nevada 330180-12-00 3300 XL Proximitor Sensor The Bently Nevada 330180-12-00, also cataloged as the 3300 XL Proximitor Sensor, operates as a dedicated hardware component for converting eddy-current proximity probe signals into proportional voltage outputs within 3300 or 3500 Machinery Protection Systems platforms. Hardware Specifications Parameter Specification Model 330180-12-00 Brand Bently Nevada Product Type 3300 XL Proximitor Sensor Origin USA Material A308 aluminum Output Resistance 50 \Omega Total Length and Mounting Option 1.0 meter (3.3 feet) system length, no mounting hardware Cable Option FluidLoc cable with connector protector Agency Approval Option Not required Operating Temperature -51 degC to +100 degC (-60 degF to +212 degF) Storage Temperature -51 degC to +105 degC (-60 degF to +221 degF) Relative Humidity Less than 3% change in Average Scale Factor (ASF) under 93% humidity per IEC 68-2-3 for up to 56 days Dimensions 8.8 x 3.5 x 7 cm Weight 0.246 kg Eddy-Current Probe Scaling and Gap Voltage Validation The 330180-12-00 conditioning electronics process radio frequency signals generated by the interconnected 5 mm or 8 mm eddy-current proximity probe. The internal circuitry establishes precise calibration limits targeting an industry-standard scale factor. During static calibration, the mechanical gap between the probe tip and the target rotor material maps to a linear DC voltage output. Field operators must verify the quiescent gap voltage validation, targeting a nominal -10 VDC center point within the linear range, ensuring optimal dynamic range for capturing high-frequency rotor dynamics and cross-talk suppression in multi-channel configurations. Frequently Asked Questions Q: What input components are electrically compatible with the 330180-12-00? A: The sensor accepts input from one non-contacting 3300-series 5 mm probe, 3300 8 mm probe, or 3300 XL 8 mm proximity probe and associated extension cable configured for a 1.0 meter system length. Q: How does environmental moisture affect the performance metrics of this hardware? A: The physical housing and internal circuitry exhibit robust resistance to moisture ingress, demonstrating less than a 3% shift in the Average Scale Factor (ASF) when subjected to 93% relative humidity conditions for 56 consecutive days in compliance with IEC standard 68-2-3. Field Installation Guidelines System Length Tuning: Ensure the total combined physical length of the proximity probe and the extension cable precisely matches the 1.0 meter calibration rating of the 330180-12-00 sensor. Discrepancies in total system length will degrade the accuracy of the scale factor calibration. Isolation and Grounding: Install the Proximitor housing such that it remains electrically isolated from structural machinery ground. Use the integrated isolation pads or dedicated DIN-rail mounting tracks to prevent ground loop noise from corrupting the low-level signal output. Connector Protection: Secure the FluidLoc coaxial connectors within the provided connector protectors. Avoid applying a bend radius tighter than 25.4 mm (1.0 inch) to the terminal extension coaxial lines to prevent internal conductor degradation.
$200.00 $100.00
-
Bently Nevada Bently Nevada 330100-90-05 3300 Proximitor Sensor
Bently Nevada 330100-90-05 3300 Proximitor Sensor The Bently Nevada 330100-90-05, also cataloged as the 330100 Proximitor Sensor, operates as a dedicated hardware component for eddy-current probe signal conditioning within 3500 and 3300 Machinery Protection System platforms. Suffix Breakdown & Model Matrix The alphanumeric suffix codes define the physical configuration and certification compliance for this specific hardware assembly: 90: Total Length Option. Calibrated for 9.0 metres (29.5 feet) of total system length (combined proximity probe and extension cable). 05: Agency Approval Option. Multiple Approvals specification for international hazardous area certifications. Hardware Specifications Parameter Specification Model 330100-90-05 Brand Bently Nevada Origin USA Weight 0.29 kg Dimensions 20.4 x 22.2 x 3.7 cm Power Supply 24 VDC Nominal Operating Temp -51 degC to +100 degC System Length 9.0 metres Approvals Multiple Approvals (Option 05) Eddy-Current Probe Scaling and Gap Voltage Validation The 330100-90-05 conditions high-frequency RF signals to measure static and dynamic distances between the probe tip and the target rotor surface. During installation and routine calibration, gap voltage validation requires setting the static DC bias point to a -10 VDC target, corresponding to the linear center of the eddy-current probe scaling profile. Cross-talk suppression circuitry minimizes electromagnetic interference from adjacent channels when probes are mounted in close proximity on the machine case, maintaining signal integrity for precise rotordynamics analysis. Frequently Asked Questions Q: What is the critical consideration for matching the 330100-90-05 with cables and probes? A: The 90 suffix specifies a 9.0 metres system length. The sensor must be matched with a combination of proximity probe and extension cable that equals exactly 9.0 metres in total physical length to prevent errors in the 7.87 V/mm (200 mV/mil) scale factor. Q: Can this sensor be hot-swapped while the machinery protection monitor is live? A: No, removing or connecting the sensor under power can cause transient voltage spikes that may trigger false trips on the Machinery Protection System. The channel should be bypassed or the system powered down prior to hardware replacement. Q: How does the sensor handle hazardous area classifications? A: The 05 option provides Multiple Approvals, which means the device satisfies European (ATEX/IECEx) and North American (CSA) requirements for intrinsic safety and non-incendive installations when installed with approved intrinsic safety barriers. Field Installation Guidelines Mechanical Mounting: Secure the Proximitor Sensor housing to a clean, flat surface inside a weather-proof environmental enclosure. Ensure it is isolated from structural vibrations and high-voltage conduits. Shielding and Grounding: Terminate the coaxial cable shield at the designated instrument ground bus within the monitor cabinet. Avoid multiple ground points to prevent ground loops that disrupt the eddy-current measurement. Bending Radius: Maintain the manufacturer's minimum bending radius specifications for the extension cable to preserve the RF impedance characteristics of the coaxial core. Do not use sharp bends or tightly cinched zip ties.
$200.00 $100.00
-
Bently Nevada 3300 XL 8mm Proximity Probe Bently Nevada 330100-90-02
Bently Nevada 330100-90-02 3300 XL 8mm Proximity Probe The Bently Nevada 330100-90-02, also cataloged as the 330100 Proximity Probe, operates as a dedicated hardware component for non-contact displacement transduction within 3300 XL eddy current transducer systems. It generates an RF carrier signal reflection proportional to the air gap between the probe tip and a conductive target surface. Suffix Breakdown & Model Matrix Code Definition 330100 3300 XL 8mm Proximity Probe, 3/8-24 UNF threads, smooth jacket -90 Unthreaded length: 9.0 inches (229 mm) -02 Overall case length: 2.0 inches (51 mm) Hardware Specifications Parameter Specification Model Brand Bently Nevada Origin USA Weight Not specified in source data Dimensions Thread: 3/8-24 UNF; Unthreaded: 229 mm; Case: 51 mm Operating Temp -52 degC to +177 degC Power Consumption Passive sensor; powered via external Proximitor Sensor Target Material AISI 4140 Steel Linear Range 2.0 mm (80 mils) Scale Factor 7.87 V/mm (200 mV/mil) Frequency Response 0 Hz to 10 kHz Probe Tip Material Polyphenylene sulfide (PPS) Probe Case Material 303 Stainless Steel Connector Gold-plated coaxial ClickLoc Tensile Strength 330 N (75 lbf) max pull Eddy-Current Probe Scaling and Gap Validation The probe exhibits a scale factor of 7.87 V/mm when terminated into a standard 3300 XL Proximitor Sensor. System linearity remains within +/- 0.038 mm across the 2.0 mm span. During installation, gap voltage validation targets -10 VDC relative to the Proximitor ground plane to ensure correct mechanical clearance and coil resistance alignment prior to turbine roll. Frequently Asked Questions Q: Is the 330100-90-02 compatible with older 3300 series extension cables? A: No. The 3300 XL probes require 3300 XL extension cables to maintain impedance matching and RF characteristics. Mixing with non-XL components alters the scale factor and invalidates calibration. Q: What is the minimum bend radius for the probe cable? A: Maintain a minimum bend radius of 25.4 mm (1 inch) to prevent dielectric stress and signal attenuation in the coaxial assembly. Q: Does the probe require calibration when replacing a damaged unit? A: No. Probes are interchangeable within the same model number without recalibration, provided the mating Proximitor Sensor and extension cable remain unchanged. Field Installation Guidelines Install the probe ensuring the unthreaded section clears the machine housing bore. Torque the 3/8-24 UNF threads to 8.5 N-m (75 in-lb) using two wrenches to prevent case rotation. Ground the outer shield of the extension cable to the machinery case at the probe entry point only. Verify the probe tip does not contact the shaft during maximum axial excursion.
$200.00 $100.00
-
Bently Nevada 330100-90-01 3300 XL 8mm Proximity Probe | Bently Nevada
Bently Nevada 330100-90-01 3300 XL 8mm Proximity Probe The Bently Nevada 330100-90-01, also cataloged as the 330100 proximity probe, operates as a dedicated hardware component for non-contacting displacement measurement within the 3300 XL eddy current transducer system. It generates an RF signal to detect ferrous target position via electromagnetic induction, outputting a linear DC voltage proportional to shaft proximity. Suffix Breakdown & Model Matrix Suffix Definition 330100 Base model: 3300 XL 8mm probe, 3/8-24 UNF threads -90 Unthreaded length: 9.0 inches -01 Total case length: 1.0 inch Hardware Specifications Parameter Specification Model Brand Bently Nevada 330100-90-01 Origin USA Weight Approx. 0.15 kg (probe assembly) Dimensions Thread: 3/8-24 UNF; Case L: 1.0 in; Unthreaded L: 9.0 in Operating Temp -51 degC to +177 degC Power Consumption Passive device; powered via external Proximitor Linear Range 2.0 mm (80 mils) Scale Factor 7.87 V/mm (200 mV/mil) ±5% (AISI 4140) Frequency Response 0 Hz to 10 kHz (+0, -3 dB) Probe Tip Material Polyphenylene sulfide (PPS) Case Material 303 Stainless Steel Eddy-Current Probe Scaling and Gap Validation The probe exhibits a scale factor of 7.87 V/mm when calibrated against AISI 4140 steel targets. During installation, gap voltage validation must target -10 VDC at the Proximitor terminal to ensure the target resides within the linear range. The system suppresses cross-talk between adjacent probes by maintaining a minimum separation distance equal to the probe diameter (8 mm) plus 25.4 mm. Signal linearity degrades if the target surface finish exceeds 63 micro-inches RMS or if non-ferrous materials alter the eddy-current damping characteristics. Frequently Asked Questions Q: Does the probe require calibration when replacing a failed unit in the field? A: No. The 3300 XL probes are mechanically and electrically interchangeable without field calibration. Calibration is performed at the factory; swap the probe and verify the -10 VDC gap voltage at the monitor. Q: What is the maximum permissible cable bend radius during installation? A: Maintain a minimum bend radius of 25.4 mm (1.0 inch) for the probe's integral coaxial cable to prevent dielectric insulation failure and signal attenuation. Q: Can this probe be submerged in oil? A: Submersion is permitted only when the probe-to-cable connector interface is protected by a certified epoxy boot or heat-shrink sealing. Without sealing, operation is limited to 100% condensing humidity environments. Field Installation Guidelines Install the probe ensuring the threads engage a minimum of five full turns into the machined mounting bracket. Torque the locknut to 8-10 N-m (71-89 in-lb) to prevent vibrational loosening. Ground the probe shield drain wire directly to the machine case at the entry point to the junction box; do not ground at both ends to avoid ground loops. Verify clearance between the probe tip and the rotating shaft does not fall below 0.25 mm (10 mils) during maximum excursion to prevent tip damage.
$200.00 $100.00
-
Bently Nevada 3300 Proximitor Sensor | 330100-50-05 | Bently Nevada
Bently Nevada 330100-50-05 3300 Proximitor Sensor Configured for eddy-current displacement transduction in the Bently Nevada 3300 monitoring system, the Bently Nevada 330100-50-05 (330100 Proximitor Sensor) provides direct electrical execution of shaft vibration and position signals via a 5-meter integral cable. Hardware Specifications Parameter Specification Model Brand Bently Nevada Origin USA Weight 0.3 kg Dimensions 6 x 5 x 8 cm Operating Temp -51 degC to +100 degC Storage Temp -51 degC to +100 degC Power Consumption 24 VDC Loop Powered Cable Length 5.0 meters (16.4 feet) Agency Approval Multiple Approvals (Option 05) Housing Material A383 Aluminum Eddy-Current Probe Scaling and Gap Validation The unit maintains a linear scale factor consistent with 3300 XL 5 mm and 8 mm probe standards. Gap voltage validation targets a nominal -10 VDC null point to ensure accurate proximity measurements. Cross-talk suppression is achieved through shielded twisted-pair cabling and specific impedance matching at the termination block, isolating rotor dynamic signals from adjacent transducer circuits during high-frequency shaft oscillation events. Frequently Asked Questions Q: What is the acceptable gap voltage range for this sensor when paired with an 8 mm probe? A: The target gap voltage is -10 VDC; operational tolerance typically resides within -9 VDC to -11 VDC depending on probe tip geometry and extension cable length. Q: Is this module compatible with the 3300 XL series front-end monitors? A: Yes, the 330100-50-05 interfaces directly with 3300 XL monitoring racks but requires verification of the system configuration software to match the 5-meter cable impedance. Field Installation Guidelines Mount the sensor housing to a rigid, non-vibrating panel surface using standard DIN-rail or bracket hardware. Ensure the 5-meter cable shield terminates at a single ground point at the monitor chassis to prevent ground loops. Do not route the signal cable in parallel with AC power conductors exceeding 200 VAC. Verify the gap voltage at the monitor terminal before energizing the machinery to prevent probe-to-shaft contact damage.
$200.00 $100.00
-
Schneider Electric Backplane Extension Cable Schneider Electric BMXXBE2005
Schneider Electric BMXXBE2005 Backplane Extension Cable TheSchneider Electric BMXXBE2005serves astheprimaryBMXXBE1000Backplane Extension Cableutilized toexecute backplane signal routing extension acrossModicon M340platforms. Configured fordeterministic backplane bus interconnection inModicon M340system architecture,theSchneider Electric BMXXBE2005(BMXXBE1000Backplane Extension Cable)provides direct physical/electricalexecution. Suffix Breakdown & Model Matrix No explicit suffix segmentation or structured decoding data is defined for BMXXBE2005. The identifier is treated as a single-order commercial and engineering part number mapped to the BMXXBE1000 backplane extension ecosystem. Hardware Specifications Parameter Specification ModelBrand Schneider Electric BMXXBE2005 Origin France Weight 1.36 kg Dimensions Cable length 12 m OperatingTemp 0 degC to 40 degC PowerConsumption N/A (passive cable assembly) Core Function Backplane extension signal interconnect Compatibility Modicon M340, BMXXBE1000 PLC Backplane Bus Communication Characteristics The BMXXBE2005 is integrated into Modicon M340 backplane topology where signal integrity is maintained through shielded multi-core transmission geometry. Within Schneider Electric PLC architectures, backplane communication velocity is governed by deterministic internal bus scheduling, ensuring synchronized module-level exchange without external protocol arbitration. The cable assembly supports firmware-level compatibility constraints defined by rack interconnection rules, including slot-to-slot timing alignment and I/O density scaling limitations across extended racks. Electrical continuity is maintained through factory-terminated line interfaces, minimizing impedance discontinuities across extended backplane segments. Frequently Asked Questions Q: Can BMXXBE2005 be hot-swapped during system operation?A: No. Backplane extension cables require system power removal before installation or removal to avoid backplane bus corruption. Q: Does the cable affect backplane cycle timing in Modicon M340 systems?A: The cable itself is passive; however, extended rack configurations may introduce measurable propagation delay within backplane synchronization limits defined by the controller firmware. Q: Is shielding continuity required during installation?A: Yes. Shield continuity must be maintained across the full 12 m run to preserve electromagnetic compatibility across the backplane segment. Field Installation Guidelines Ensure all Modicon M340 racks are powered down prior to installation. Route the 12 m cable along controlled cable trays with minimum bending radius compliant with industrial shielded cable practice. Maintain continuous grounding of cable shielding at designated rack grounding points to prevent differential potential buildup. Avoid parallel routing with high-voltage switching conductors to reduce inductive coupling. Verify full seating of BMXXBE1000-compatible connectors before system re-energization.
$200.00 $100.00
-
Bently Nevada 3300 Proximitor Sensor | Bently Nevada 330100-50-02
Bently Nevada 330100-50-02 3300 Proximitor Sensor TheBently Nevada 330100-50-02serves astheprimary330100Proximity Sensorutilized toexecuteeddy-current based shaft displacement measurement across 3300 XL Proximitor Sensor platforms. Configured for non-contact gap and vibration transduction in conjunction with a 3300 XL Proximitor conditioning module, theBently Nevada 330100-50-02(330100Proximity Sensor) provides direct physical/electrical execution of radial shaft position sensing via calibrated oscillatory field collapse detection. Suffix Breakdown & Model Matrix 330100: 3300 XL 8 mm proximity probe mechanical format (3/8-24 UNF mounting thread class) -50: probe unthreaded length configuration (5.0 in class definition) -02: case length configuration (2.0 in class definition) Cable length option referenced in system configuration (extension dependent, system-level assembly) Hardware Specifications Parameter Specification ModelBrand Bently Nevada 330100-50-02 Origin USA Weight 0.29 kg Dimensions Not specified (probe geometry: 8 mm class body, 3/8-24 UNF thread) OperatingTemp -51 degC to +177 degC PowerConsumption Passive sensor (requires external proximitor excitation) Probe Diameter 8 mm Thread 3/8-24 UNF Output Principle Eddy-current displacement sensing Linear Range 2.0 mm (system dependent) Eddy-Current Scaling and Gap Voltage Validation Behavior The 3300 XL probe structure implements eddy-current field interaction with conductive shaft targets, producing a demodulated voltage proportional to probe-to-target spacing. Signal conditioning is dependent on proximitor excitation carrier stability and calibrated -10 VDC to 0 VDC gap voltage mapping. Cross-channel interference suppression is achieved through coaxial shielding integrity and ClickLoc connector impedance stability, ensuring minimal signal distortion in multi-probe installations within rotating machinery assemblies. Frequently Asked Questions Q: Can the 330100-50-02 operate without a 3300 XL Proximitor Sensor?A: No. The probe is a passive transducer and requires an external proximitor module to generate excitation and convert eddy-current impedance variation into voltage output. Q: Is the probe compatible with mixed cable lengths in a single loop?A: Only system-defined extension cables matched to the 3300 XL calibration constant are permitted. Mismatched total loop length affects scale factor linearity. Q: What is the limitation of signal integrity in high EMI environments?A: Performance depends on coaxial shielding continuity and proper grounding. Improper shield termination increases cross-talk and noise coupling. Field Installation Guidelines Maintain consistent 90 deg routing bends with minimum coaxial cable stress radius compliance Ensure probe tip alignment perpendicular to target shaft surface to preserve eddy-current linearity Ground cable shield at single-point system reference only to avoid ground loop current Verify probe gap calibration using static shaft reference before dynamic commissioning Avoid mechanical preload on probe tip during installation torqueing sequence
$200.00 $100.00
-
Bently Nevada Bently Nevada 330100-50-01 | Proximity Probe
Bently Nevada 330100-50-01 Proximity Probe TheBently Nevada 330100-50-01also cataloged asthe330100-50-01 Proximity Probe serves astheprimary330100-50-01 Proximity Probeutilized to execute non-contact shaft displacement and vibration gap measurement across Bently Nevada 3300 XL eddy-current transducer platforms. Configured for non-contact displacement sensing in eddy-current measurement chains, the Bently Nevada 330100-50-01 (330100-50-01 Proximity Probe) provides direct physical/electrical execution via induced field interaction between probe tip and conductive rotor surfaces within the 3300 XL monitoring system. Suffix Breakdown & Model Matrix 330100: 8 mm 3300 XL proximity probe platform -50: 5.0 inch probe body length (unthreaded section) -01: 1.0 inch case / connector configuration variant No additional factory configuration data beyond ordering code is provided. Hardware Specifications Parameter Specification ModelBrand Bently Nevada 330100-50-01 Origin Not specified Weight 0.50 lbs Dimensions Not specified (8 mm probe diameter, 3/8-24 UNF thread interface) OperatingTemp -51 degC to +177 degC PowerConsumption Passive (eddy-current probe, no direct supply) Probe Type 8 mm Eddy Current Proximity Probe Linear Range 2.0 mm (approx.) Calibration Target AISI 4140 steel Output Interface Requires 3300 XL Proximitor system Eddy Current Scaling and Rotor Dynamic Behavior (Bently Nevada TSI Domain) The 330100-50-01 operates under eddy-current transduction principles where coil impedance variation is converted into proportional gap voltage within the 3300 XL Proximitor system. Signal linearity is maintained through factory scaling against conductive rotor targets, typically normalized to AISI 4140 steel reference surfaces. Gap voltage validation is referenced against negative DC bias operating regions (commonly around -10 VDC conditioning domain in system-level proximitor architecture), ensuring stable conversion across the linear measurement zone. Rotor dynamic interpretation relies on phase-coherent sampling of vibration vectors derived from shaft radial displacement. Cross-talk suppression is achieved through coaxial shielding geometry and controlled excitation frequency isolation within the probe-extension-proximitor chain, minimizing electromagnetic coupling between adjacent channels in multi-probe installations. Frequently Asked Questions Q: Can the 330100-50-01 operate without a 3300 XL Proximitor?A: No. The probe is a passive sensing element and requires a matched 3300 XL Proximitor for signal excitation and linear conversion. Q: Is the probe electrically isolated from the machinery ground?A: The sensing tip is electrically isolated; however, system grounding depends on installation of the extension cable shield and proximitor grounding scheme. Q: What happens if cable length is mismatched in the system chain?A: Incorrect total system length alters calibration scaling factor and introduces measurement gain error across the full displacement range. Field Installation Guidelines Maintain minimum bend radius of 25.4 mm for coaxial cable routing Ensure probe tip alignment perpendicular to shaft surface for linear response stability Verify 3/8-24 UNF thread engagement with controlled torque to avoid housing stress Route coaxial cable away from high-voltage switching conductors to reduce induced noise Maintain shield continuity from probe body through extension cable to proximitor ground reference Confirm probe-to-target gap within linear operating region before system commissioning
$200.00 $100.00
-
Bently Nevada Bently Nevada 330100-50-00 3300 Proximitor Sensor
Bently Nevada 330100-50-00 3300 Proximitor Sensor Configured for proximity probe signal conditioning in 3300 Machinery Monitoring System,the Bently Nevada 330100-50-00 (330100-50-00 3300 Proximitor Sensor) provides direct physical/electrical execution of eddy-current probe gap voltage conversion and linearized displacement output. The module functions as a signal conditioning interface for Bently Nevada 3300 series proximity transducers, converting high-frequency probe oscillation into a stable DC output proportional to shaft radial vibration and position. It is designed for fixed-installation machinery monitoring where continuous gap voltage validation and linear range tracking are required. The unit supports extended probe cable termination up to 5 m total length configuration (50 option), with factory-defined calibration for standard 3300 system probe scaling. Hardware Specifications Parameter Specification ModelBrand Bently Nevada 330100-50-00 Origin USA PowerConsumption Powered via 3300 rack system backplane (exact load not specified) ProductType Proximitor Sensor Total Cable Length 5 m (16.4 ft) System Compatibility Bently Nevada 3300 Monitoring System Signal Type Eddy-current probe conditioned voltage output Bently Nevada Eddy-Current Signal Conditioning Characteristics The 330100-50-00 operates within Bently Nevada 3300 proximity measurement architecture and is matched to eddy-current probe scaling characteristics. The internal conditioning stage maintains probe gap voltage linearization typically referenced against negative DC bias scaling (commonly centered around -10 VDC operating range within system calibration envelopes). This ensures stable displacement conversion under varying shaft material conductivity and environmental electromagnetic influence. Cross-talk suppression is implemented at the conditioning interface level to reduce interference between adjacent probe channels in multi-channel rack configurations. The signal path is optimized for rotor dynamics monitoring, where phase-stable waveform integrity is required for orbit analysis and shaft centerline tracking. Suffix Breakdown & Model Matrix 330100: 3300 Proximitor Sensor base module 50: Total cable length option (5 m) 00: Agency approval not required configuration Frequently Asked Questions Q: Can the 330100-50-00 be hot-swapped in a live 3300 rack system?A: It is not designed for energized insertion or removal. System backplane interaction should be de-energized to avoid transient probe bias disruption and channel calibration drift. Q: Does the module require individual channel calibration after replacement?A: Calibration consistency is maintained through system-defined probe scaling; however, verification of gap voltage alignment is required after installation to confirm stable DC output baseline. Q: What is the impact of extended probe cable length on signal stability?A: Cable length affects capacitive loading on the eddy-current probe circuit. The 5 m configuration is factory-compensated, but improper routing can introduce attenuation and phase noise. Field Installation Guidelines Maintain separation between probe wiring and high-voltage conductors to reduce electromagnetic coupling effects. Use shielded cable with single-point grounding at the monitoring rack end only. Avoid sharp bends in probe extension cables to preserve impedance consistency. Ensure secure seating in 3300 system rack to maintain backplane contact integrity. Verify probe gap voltage stability after power-up before enabling alarm thresholds.
$200.00 $100.00
